SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
283
Versions
Terminal module for contactors with screw connection
3RT1900-4RE01
plugs S00, S0
3RT1916-4RD01
adapter S00
3RT1926-4RD01
adapter S0
General data
CSA and UL rated data
 Rated operational voltage U
e
V 480
 Rated insulation voltage U
i
V 600
 Continuous current, at 40 °C
A 16 / 25 16 25
 Short-circuit protection
1)
 At 600 V
kA 5
 Fuse class RK5
A 100 60 100
 Circuit breakers
with overload
protection acc. to
UL 489
A 100 60 100
1)
For more detailed information about short-circuit values, e.g. for protection against high short-circuit currents, see the UL
reports (http://www.siemens.com/lowvoltage/support) for the individual devices.
Combination motor controller type E to UL 508
Type 3RV202
A 22 --- 22
 At 480 V
kA 65 --- 65
Type 3RV202
A 22 --- 22
 At 600 V
kA 10 --- 10
