SIRIUS 3RU2/3RB3 overload relays
5.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
553
3RU2116-..C0 (S00)
94
35
5
64
45
136
Figure 5-9 3RU2116-..C0
3RU2116-..C1 (S00)
80
51
5
60
56
45
102
Figure 5-10 3RU2116-..C1
