SIRIUS 3RA21/22 load feeders
6.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
629
Figure 6-21 S0 reversing starter, AC with spring-loaded connection system
3RA2220-..F..-0AP0
Figure 6-22 S0/S0 and S00/S0 reversing starters, DC, screw-type connection system
3RA2220-..B..-0BB4
