SIRIUS 3RA21/22 load feeders
6.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
631






Figure 6-25 S00 reversing starter, AC/DC, screw-type connection system
3RA2210-..D







Figure 6-26 S00 direct-on-line starter, AC/DC, spring-loaded connection system
3RA2110-..H
