SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
7.6 Mounting
SIRIUS Innovations
664 System Manual, 01/2011, A8E56203870002-03
Step Operating instruction Figure
5 Push the interlock slide down with a
screwdriver until it engages.

6 Insert the coded module connector into
the slot in the correct position from
above until the module connector
engages in the locking mechanism.
7 To complete the process, lock the
module connector.




