System overview
1.8 Mounting and disassembly
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
73
Table 1- 23 Disassembling from a DIN rail
Step Operating instruction Image
1 To disassemble the device, press it down,
pushing against the mounting springs.
Swivel the device to remove it.
Refer to the relevant product chapters, product manuals, or operating instructions for specific
details of how to snap the different devices onto DIN rails.
