SIRIUS 3RR2 current monitoring relays
8.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
751
3RR2142-1A.30 (screw connection, S0)
With contactor With terminal support for stand-alone assembly
D
3RR2142-2A.30 (spring-loaded connection, S0)
With contactor With terminal support for stand-alone assembly
