Siemens SIRIUS 3RW44 2 Series - Delta Circuit Configurations and Ratings; Delta Circuit Motor Output (40°C); Delta Circuit Motor Output (50°C)

English
22 3ZX1012-0RW44-1AA1
Inside delta circuit Inside delta circuit
Ambient temperature 40 °C Ambient temperature 50 °C
Rated
operating
voltage U
e
Rated
operating
current I
e
Rated output of three-phase
induction motors for rated
operating voltage U
e
Rated
operating
current I
e
Rated output of three-phase
induction motors for rated
operating voltage U
e
Order No.
V A
230 V
kW
400 V
kW
500 V
kW
A
200 V
HP
230 V
HP
460 V
HP
200 ... 400 50 15 22 — 45 10 15 — 3RW44 22-@BC@4
62 18,5 30 — 55 15 20 — 3RW44 23-@BC@4
81 22 45 — 73 20 25 — 3RW44 24-@BC@4
99 30 55 — 88 25 30 — 3RW44 25-@BC@4
133 37 75 — 118 30 40 — 3RW44 26-@BC@4
161 45 90 — 142 40 50 — 3RW44 27-@BC@ 4
400 ...600 50 — 22 30 45 — — 30 3RW44 22-@BC@5
62 — 30 37 55 — — 40 3RW44 23-@BC@5
81 — 45 45 73 — — 50 3RW44 24-@BC@5
99 — 55 55 88 — — 60 3RW44 25-@BC@5
133 — 75 90 118 — — 75 3RW44 26-@BC@ 5
161 — 90 110 142 — — 100 3RW44 27-@BC@5
400 ... 690 50 — 22 30 45 — — 30 3RW44 22-@BC@ 6
62 — 30 37 55 — — 40 3RW44 23-@BC@6
81 — 45 45 73 — — 50 3RW44 24-@BC@6
99 — 55 55 88 — — 60 3RW44 25-@BC@6
133 — 75 90 118 — — 75 3RW44 26-@BC@ 6
161 — 90 110 142 — — 100 3RW44 27-@BC@6
Order No. extension for connection method Screw-type terminals
Spring-loaded terminals
200 ... 400
196 55 110 — 173 50 60 — 3RW44 34-@BC@4
232 75 132 — 203 60 75 — 3RW44 35-@BC@4
281 90 160 — 251 75 100 — 3RW44 36-@BC@ 4
352 110 200 — 312 100 125 — 3RW44 43-@BC@4
433 132 250 — 372 125 150 — 3RW44 44-@BC@4
542 160 315 — 485 150 200 — 3RW44 45-@BC@4
617 200 355 — 546 150 200 — 3RW44 46-@BC@4
748 250 400 — 667 200 250 — 3RW44 47-@BC@4
400 ... 600
196 — 110 132 173 — — 125 3RW44 34-@BC@5
232 — 132 160 203 — — 150 3RW44 35-@BC@5
281 — 160 200 251 — — 200 3RW44 36-@BC@5
352 — 200 250 312 — — 250 3RW44 43-@BC@5
433 — 250 315 372 — — 300 3RW44 44-@BC@5
542 — 315 355 485 — — 400 3RW44 45-@BC@5
617 — 355 450 546 — — 450 3RW44 46-@BC@5
748 — 400 500 667 — — 600 3RW44 47-@BC@5
400 ... 690
196 — 110 132 173 — — 125 3RW44 34-@BC@6
232 — 132 160 203 — — 150 3RW44 35-@BC@6
281 — 160 200 251 — — 200 3RW44 36-@BC@6
352 — 200 250 312 — — 250 3RW44 43-@BC@6
433 — 250 315 372 — — 300 3RW44 44-@BC@6
542 — 315 355 485 — — 400 3RW44 45-@BC@6
617 — 355 450 546 — — 450 3RW44 46-@BC@6
748 — 400 500 667 — — 600 3RW44 47-@BC@6
Order No. extension for connection method
Order no. extension for rated control supply voltage U
s
Spring-loaded terminals
Screw-type terminals
AC 115 V
AC 230 V
1
3
2
6
3
4
