Product versions
4.1 Device versions
3TK2826 safety relay
12 Manual, 08/2007, GWA NEB 926 1579-02 DS 02
● Delayed enabling circuits
24V DC
24V AC/DC to 240V AC/DC
Y22 T2 Y34 74 84 A2
14 24 32 48 58 62
13 23 31 47 57 61
A1 Y12 T1 Y33 T3 1
3TK2826-1BB44
SIEMENS
SIEMENS
SIRIUS
DEVICE
OUT
IN
SF
SET / RESET
1
2
3
4
5
6
7
8
5
50
100
150
200
300s
Figure 4-2 3TK2826 safety relay with relay enabling circuits,
stop category 0/1 in accordance with EN 60204-1
