Siemens Sirius 3TK2826 User Manual

3TK2826 safety relay
Manual, 08/2007, GWA NEB 926 1579-02 DS 02
9
Product family
3
3.1 Order numbers
Table 3-1 Order numbers for the device versions
Stop
cat.
Rated control
supply voltage
Cutout delay (s) Order No.: *)
0 24V DC 0 3TK2826-.BB40
0 24V AC/DC to 240V AC/DC 0 3TK2826-.CW30
0/1 24V DC 0,05 … 3 3TK2826-.BB41
0/1 24V AC/DC to 240V AC/DC 0,05 … 3 3TK2826-.CW31
0/1 24V DC 0,5 … 30 3TK2826-.BB42
0/1 24V AC/DC to 240V AC/DC 0,5 … 30 3TK2826-.CW32
0/1 24V DC 5 … 300 3TK2826-.BB44
0/1 24V AC/DC to 240V AC/DC 5 … 300 3TK2826-.CW34
*)
8th position in order no.: 1 = screw terminal, 2 = spring-loaded terminal
Signaling outputs Stop
cat.
Rated control
supply voltage
Safe
outputs(floating)
Floating Non-float.
Order No.:*)
Undelay
ed
NO
Time-
del.
NO
Undelay
ed
NO
Undelay
ed
NC
Time
-
del.
NC
NO
0 24V DC 4 0 0 1 0 2 3TK2826-.BB40
0 24V AC/DC to 240V AC/DC 4 0 1 1 0 0 3TK2826-.CW30
0/1 24V DC 2 2 0 1 1 2 3TK2826-.BB41
0/1 24V AC/DC to 240V AC/DC 2 2 1 1 1 0 3TK2826-.CW31
0/1 24V DC 2 2 0 1 1 2 3TK2826-.BB42
0/1 24V AC/DC to 240V AC/DC 2 2 1 1 1 0 3TK2826-.CW32
0/1 24V DC 2 2 0 1 1 2 3TK2826-.BB44
0/1 24V AC/DC to 240V AC/DC 2 2 1 1 1 0 3TK2826-.CW34
*)
8th position in order no.: 1 = screw terminal, 2 = spring-loaded terminal
