4 Bestell-Nr. / Order No.: 3ZX1012-0RB30-1AA1
DE Anschließen ES Conexión TR Bağlantı
EN Connect IT Collegamento РУ Подсоединение
FR Branchement PT Conexão
中文 连接
3RB3.1.-.... (S00)
2T1 / 4T2 / 6T3, 14 / 22 / A2 A3- / A4+ / 95 / 96 / 97 / 98
3RB3.1.-..B. 3RB3.1.-..E. 3RB3.1.-..B. 3RB3.1.-..E.
PZ 2 (∅ 5 ... 6 mm)
0,8 ... 1,2 Nm
(7 to 10.3 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
PZ 2 (∅ 5 ... 6 mm)
0,8 ... 1,2 Nm
(7 to 10.3 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
2 x (0,5 ... 1,5) mm
2
IEC 60947: 2 x (0,75 ... 2,5) mm
2
max. 2 x (1 ... 4) mm
2
1 x (0,5 ... 4,0) mm
2
1 x (0,5 ... 4) mm
2
2 x (0,5 ... 2,5) mm
2
2 x (0,25 ... 1,5) mm
2
—
1 x (0,5 ... 2,5) mm
2
— 2 x (0,25 ... 1,5) mm
2
2 x (0,5 ... 1,5) mm
2
2 x (0,75 ... 2,5) mm
2
1 x (0,5 ... 2,5) mm
2
1 x (0,5 ... 2,5) mm
2
2 x (0,5 ... 1,5) mm
2
2 x (0,25 ... 1,5) mm
2
AWG
2x(20to12)
1x12
1 x (20 to 12) 2 x (20 to 14) 2 x (24 to 16)
3RB3.2.-.... (S0)
2T1 / 4T2 / 6T3 A3- / A4+ / 95 / 96 / 97 / 98
3RB3.2.-..B. 3RB3.2.-..E. 3RB3.2.-..B. 3RB3.2.-..E.
PZ 2 (∅ 5 ... 6 mm)
2 ... 2,5 Nm
(18 to 22 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
PZ 2 (∅ 5 ... 6 mm)
0,8 ... 1,2 Nm
(7 to 10.3 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
2 x (1,0 ... 2,5) mm
2
2 x (2,5 ... 10) mm
2
1 x (1,0 ... 10) mm
2
1 x (0,5 ... 4) mm
2
2 x (0,5 ... 2,5) mm
2
2 x (0,25 ... 1,5) mm
2
—
1 x (1,0 ... 6,0) mm
2
— 2 x (0,25 ... 1,5) mm
2
2x(1...2,5)mm
2
IEC 60947: 2 x (2,5 ... 6,0) mm
2
max. 1 x 10 mm
2
1 x (1,0 ... 6,0) mm
2
1 x (0,5 ... 2,5) mm
2
2 x (0,5 ... 1,5) mm
2
2 x (0,25 ... 1,5) mm
2
AWG
2x(16to14)
2x(14to8)
1 x (18 to 8) 2 x (20 to 14) 2 x (24 to 16)
U = 0 V
DE Abnehmbare Klemme austauschen
EN Replacing the removable terminal
FR Remplacer la borne amovible
ES Sustituir el borne desmontable
IT Sostituzione del morsetto rimovibile
PT Substituir o terminal removível
TR Çıkarılabilir klemensleri değiştiriniz
РУ Заменить съемную клемму
中文 更换可拆装式接线盒
1
3
2
4
5
~10°
~10°
3RA2908-1A Ø 3,0 x 0,5 [mm]
0,5 mm
3 mm
