Siemens SIRIUS Configuration Manual

Installation guidelines
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
93
Combination
Output
Distance between feeders
Permissible installation: h = horizontal, v = vertical
Max. ambient temperature
Vibration and shock
1
Motor starter protector and
contactor
A mm h, v °C
3RA22 reversing starter, spring-loaded terminal, busbar
0 h 60 ≤ 14
0 v 40
10 h 60
S00
14 … 16
10 v 40
Vibration and shock kit 8US1998-1CA10 required
0 h 60 ≤ 29
0 v 40
10 h 60
S0
29 … 32
10 v 40
Vibration and shock kit 8US1998-1CA10 required
Motor starter protector and soft starter, screw terminal, DIN rail or wall
S00 16
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
S0 32
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
Motor starter protector and soft starter, spring-loaded terminal, DIN rail or wall
S00 16
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
S0 32
2) 2)
The feeder must be screwed tight to the top of the motor
starter protector with two screws and fastened to the
bottom of the soft starter with a self-locking screw. Not
approved for railways, power plants, or shipbuilding.
Motor starter protector and solid-state contactor, screw terminal, DIN rail or wall
Direct starter
2) 2)
Unlimited Not approved for railways, power plants, or
shipbuilding.
Reversing starter
2) 2)
Unlimited Not approved for railways, power plants, or
shipbuilding.
1)
Vibration and shock tests are carried out in accordance with SN 31205 as well as with the relevant standards for
railways, shipbuilding, and power plants.
2)
Please consult Technical Assistance (www.siemens.com/industrial-controls/technical-assistance).

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
