Integration of a SITOP 24V power supply in PCS 7
Entry ID: 10948108, V3.2, 01/2019
Siemens AG
2019 All rights reserved
1.4 Components used
This application example was created with these hardware and software
components.
Hardware components
Table 1-1
DC 24 V/10 A power supply
Selectivity module, 4x 3 A
Power supply system
DC 24 V/1x 20 A
Power supply system
DC 24 V/4x 10 A
Expansion module, 4x 10 A
Buffer module, 300 ms/40 A
Software components
Table 1-2
Standard engineering
software
Module library for SITOP
Download
Example project and files
This application example consists of the following components:
Table 1-3
PCS 7 Multi-project archive
109481908_PCS 7_SITOP24V_Demo_V32.zip
109481908_PCS 7_SITOP24V_Docu_V32_de.pdf
