Technical data
6.2 Output
SITOP PSU100S
42 Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
6EP1332-2BA20 6EP1333-2BA20 6EP1334-2BA20 6EP1336-2BA10
Response when
switching on/off
Overshoot of Ua<720 mV No overshoot of Ua
(soft start), with the
exception of a
capacitive load
Starting delay, max. 300 ms 300 ms 300 ms 1.5 s
Start delay, typ. 200 ms 160 ms 150 ms 500 ms
Voltage rise
120 V / 230 V AC max.
100 ms 100 ms 100 ms 500 ms
Voltage rise
120 V / 230 V AC typ.
15 ms 15 ms 20 ms 50 ms
Rated current Ia rated 2.5 A 5 A 10 A 20 A
Current range
 Remark
0...2.5 A
3 A to +45° C
+60 to +70 °C;
derating: 3 % Ia
rated/K
0...5 A
6 A to +45° C
+60 to +70 °C;
derating: 3 % Ia
rated/K
0...10 A
12 A to +45° C
+60 to +70 °C;
derating: 3 % Ia
rated/K
0...20 A
24 A to +45° C
+60 to +70 °C;
derating: 5 % Ia
rated/K
Output active power /
typical
60 W 120 W 240 W 480 W
Overload capability
(Extra Power)
3.75 A for 5 s/min 7.5 A for 5 s/min 15 A for 5 s/min 30 A for 5 s/min
Short-time overload
current / for a short
circuit when powering
up / typical
9 A 18 A 33 A 35 A
Duration of the
overload capability,
overcurrent / for a
short circuit while
powering up
 Remark
800 ms
once-only
800 ms
once-only
800 ms
once-only
100 ms
every 2.5 s
Short-time overload
current / for a short
circuit in operation /
typical
9 A 18 A 33 A 35 A
Duration of the
overload capability,
overcurrent / for a
short circuit in
operation
 Remark
800 ms
once-only
800 ms
once-only
800 ms
once-only
100 ms
every 2.5 s
Can be connected in
parallel to increase the
power rating
Yes
Number of devices
that can be connected
in parallel to increase
the power rating, units
2
