Installation
5.2 Installing mounting plates
CP-S SA
24 Operating Instructions, 04/2009, A5E02522341B
Installing the load cell and pressure piece set
CAUTION
Personal injuries, damage to the load cells
Insufficiently secured loads can fall and cause injuries or material damage. Therefore,
appropriate lifting tools must be used to lift the load bearing implement. The corresponding
safety regulations must be observed.
CAUTION
Destruction of the load cells, pressure piece set and mounting plates
Check that the load cells and installation unit are installed correctly, e.g. by checking the
mounting dimensions and oscillation distances. Incorrect assembly can lead to the
destruction of the load cell and the installation unit.
Ensure that the cable does not become damaged or is cut off.
Lay the cables through cable glands in the form of a vertical downwards loop to discourage
the penetration of water.
Adapt the procedure to the installation conditions.
