SL75 Level 2 Service Manual
Copyright © Siemens Pte Ltd. Siemens Technical Support Centre
All Rights Reserved
COM D CCQ APAC SLI Page 5 of 44 Internal Use Only
3 Key Features
Bands
• Triple Band E-GSM 900 / GSM 1800 / GSM 1900
• GPRS Multi Class 10
Battery
• Li-Ion Battery Pack
• Nominal Voltage : 3.7V
• Nominal Capacity : 700 mAh
• GSM Capacity : 670 mAh
• Power Input : 2.0A (0.6 ms) / 0.25A (4 ms)
• Cut-off Threshold : 3.2V
Stand-by Time ≥ Approx. 290 h (Best Case)
Talk Time ≥ 4.7 hrs (Best Case)
SIM Card
• Small (”Plug In”) 1.8 or 3V SIM card (Phase II)
•
To insert the SIM card, the battery pack must be
removed.
Speech Codec
• Triple Rate (HR/FR/EFR) and Adaptive Multi Rate are
available as standard
Temperature
Range
• -10
0
C to +55
0
C (Normal operation)
• -30
0
C to +85
0
C (Storage capability)
Display
• Type: Full Graphic
• Resolution: 132 x 176 Pixel
• Color depth: 262K
• Technology: TFT
• Active area / mm: 27.7 x 37.0
• Illumination: White LED (4 LEDs integrated)
• Frame rate: maximum 15 frames/seconds
• Pixel size per mm: 0.21mm x 0.21mm ( 1 pixel consist
of 3 sub pixels in red, green and blue)
Keypad
• Hardcapes backside-printed
• 12-key-block (0-9, #, *)
• Dedicated operator hard key for quick and easy access to
relevant operator services
• two function keys (SEND, END)
• ON/OFF key combined with the END key; the symbol (I
inside O) is used as a symbol for ON/OFF.
• 5 way-joystick with design-cap (soft material)
• 2 soft-keys for different SW-enabled functions
• white as illumination colour
• tactile finder on key “5“
• 2x4 white LEDs for keypad (main / slider keypad)
