Circumference Measurement with a Label
1 Press Freeze.
2 Press Caliper Key.
3 Rotate SELECT control to highlight measurement from on screen menu, press SELECT control.
4 Place first caliper, press SET key.
5 Place second caliper, press SET key.
6 To adjust a caliper location- re-activate caliper by pressing the UPDATE key. (green is active)
7 Roll TRACKBALL to adjust ellipse shape, press SET key. (Ellipse can be repositioned by rolling TB)
8 Press SET key to complete measurement and send to Report.
Color and Power Doppler
To activate Color press Color Mode control. To exit press again or press 2D. To activate Power Doppler press Power Mode
control.
To adjust... …do this
ROI position Roll trackball
ROI size Press SET Key, roll trackball to adjust, press SET
Steer Press Steer/Angle control (only available on linear txs.)
Rotate to steer
Overall color/power gain Rotate color control
Frequency Toggle soft menu control
PRF (scale) Toggle soft menu control
Spectral Doppler
To activate Spectral Doppler press Doppler Mode key. Roll trackball to position cursor.
To adjust... …do this
Gate size Toggle soft key menu control
Overall Doppler gain Rotate Doppler mode
Steer Press Steer/Angle control and roll trackball to position cursor.
Angle Correct Press Steer/Angle control and rotate to adjust.
Frequency Toggle soft menu control
PRF (scale) Toggle soft menu control
Volume Toggle soft menu control
Baseline Toggle soft menu control
Obtaining OB Calculations
1 Obtain desired image, press Freeze.
2 Press CALIPER key.
3 Rotate SELECT key to highlight desired measurement from on-screen menu, press SELECT key.
4 Place first caliper, press SET key.
5 Place subsequent caliper(s), press SET key. Measurement will be displayed on screen and transferred to Worksheet.
