General Duty Switches-Features (60-600A)
1. Cover interlock
2. Tangential knockouts through
600A for easy conduit lineup
3. Quick-make, quick-break operat-
ing mechanism that ensures
positive operation
4. Provisions for T, R, J, H and
K class fuses (T & J 200-600A)
5. Generous wiring gutters that
meet or exceed NEC wire-
bending space requirements
6. Visible blade, double-break
switch action
7. Positive two- or three-point
mounting
8. Highly visible red handle grip
9. Informative door labeling
which includes replacement
parts list
10. Handle and cover
padlocking provisions
11. Side-hinged door that opens
180 degrees for easier wiring
12. A unique enclosure design that
adds rigidity and strength. Its
rolled edge prevents cuts and
scrapes to conductors and to
installers’ hands
9
1
8
6
3
5
4
7
2
12
10
11
12
