35
Dimensions shown in inches and millimeters [ ].
Dimensions shown accurate to
+
1/8 inch.
C
L
1. 0 0
[ 25.4 ]
1. 0 0
[ 25.4 ]
.31
(7.87)
.28 (7.11) DIA GROUNDING KNOCKOUT (2) PLACES
B
B
1.69
[ 42.93 ]
1.69
[ 42.93 ]
1.1 3
[ 28.7 ]
1. 3 1
[ 33.27 ]
C
L
.10
[ 2.54 ]
Type HA Outdoor
Hub Provision
5.63
[ 143.0 ]
1. 0 0
[ 25.4 ]
3.13
[ 79.50 ]
2.94
[ 74.68 ]
8.16
[ 207.26 ]
(Door)
1.1 3
[ 28.7 ]
6.13
[ 155.7 ]
8.07
[ 204.98 ]
.85
[ 21.59 ]
5.38
[ 136.65 ]
1.75
[ 44.5 ]
3.50
[ 88.9 ]
5.22
[ 132.59 ]
C
L
5.44
[ 138.18 ]
(Door)
.50
[ 12.7 ]
A
A
B
.85
[ 21.59 ]
5.94
[ 150.88 ]
1.1 3
[ 28.7 ]
2.81
[ 71.37 ]
(3) .25 (6.35) DIA
MOUNTING HOLES
14.68
373[]
32
813[]
3.20
81[]
38.40
975[]
61.25
1556[]
67.16
1706[]
24.02
610[]
30.46
774[]
13.24
336[]
13.44
341[]
66.67
1693[]
9.24
236[]
.25
6[]
40.00
1016[]
2.79
71[]
.56 Dia (4)
14[]
Type 3R (Outdoor)
30 Amp General Duty (2-Pole)
Type 1 (Indoor)
800 / 1200 Amp Heavy Duty Fusible
Figure 11
Figure 12
No knockouts in the enclosures.
KNOCKOUT CONDUIT
CODE SIZE
A (Concentric)
.50 .75
B (Concentric) .50 .75 1.00
