Ultraheat / Ultracold UH50 Configuration Instructions UH 106-101k Page 11 / 15
Log functions
Logbook
In the internal logbook, metrologically relevant
events (errors, states, actions) are stored in
chronological order with their time of occurrence.
The events acquired are predefined. The data of the
logbook cannot be deleted.
Each event is stored in a separate 4-level shift
register; the overflows are transferred to a 25-level
circulating buffer. Therefore, at least the last 4 times
can be traced for each event.
In a monthly register, the error states are stored for
the current month and for the past 18 months
(without time stamp).
Ser
No.
Type Description
1 F0 = Air in measuring tube
2 F1 = Interruption flow sensor
3 F2 = Interruption return sensor
4 F3 = Error temperature electronics
5 F5 = Short-circuit flow sensor
6 F6 = Short-circuit return sensor
7 F8 = Sensor error > 8 hours
8
Error occurs or back-to normal
F9 = ASIC error
9
Above max. temperature in the volume
measuring unit
10
Below min. temperature in the volume
measuring
11 Max. flowrate qs was exceeded
12 Soiling prewarning
13 Line voltage off
14
State occurs or ends
CRC error occurred
15 Adjustment values parameterized
16 F7-(EEPROM) pre-warning
17 Reset made
18 Date / time parameterized
19 Yearly set day parameterized
20 Monthly set day parameterized
21 Master reset performed
22 All times deleted
23 Missing time deleted
24
Event occurs
Maxima deleted
Read-out is performed via the optical interface with
the service software.
Data logger
(optional)
The data logger permits the archiving of data that the
user can select from a predefined set of values. The
data logger contains four archives whose 8 channels
can be assigned.
The data can be assigned to any of the channels.
Archive Timebase
Storage
depth
Averaging
time for
maximum
Hourly
archive
1 hour 45 days 1 hour *)
Daily
archive
1 day 65 days 1 hours
Monthly
archive
1 month 15 months 1 hours
Yearly
archive
1 year 15 years
1 hours /
24 hours
*) For a shorter measuring period than 1 hour, the
largest value from the maximum values calculated
within one hour applies.
The data are recorded with the value and time
stamp.
Parameterizing and read-out is performed via the
optical interface with the service software .
Note: Data transmission is in a manufacturer-specific
format.
Value set for data to be recorded
Meter readings
at the end of the period
for...
Quantity of energy
Tariff register 1, 2, 3
Volume
Operating duration *)
Fault duration *)
Pulse input 1
Pulse input 2
*) depending on parameter
setting: hours or days
Instantaneous values
at the end of the period
for...
Power
Flowrate
Flow temperature
Return temperature
Temperature difference
Error display
Maximum for...
Power
Flowrate
Flow temperature
Return temperature
Temperature difference
