Siemens UH50 Series Configuration Instructions

Ultraheat / Ultracold UH50 Configuration Instructions UH 106-101k Page 13 / 15
Split version with 1.5m control cable C
Split version with 3.0m control cable D
Split version with 5.0m control cable E
Compact version (until 90°C, with 0.3m control
cable),control cable removable
M
Split version with 1.5m control cable, control cable
removable
P
Split version with 3.0m control cable, control cable
removable
Q
Split version with 5.0m control cable, control cable
removable
R
4. Country / where used Code
Dial plate for Armenia (Armenian) AM
Dial plate for Austria (German) AT
Dial plate for Bosnia-Herzegovina (Croatian) BA
Dial plate for Belgium (French/Flemish) BE
Dial plate for Bulgaria (Bulgarian) BG
Dial plate for Belarus (Russian) BY
Dial plate for Switzerland (German/French) CH
Dial plate for China (Chinese) CN
Dial plate for Serbia and Montenegro (Serbian) CS
Dial plate for Czech Republic (Czech) CZ
Dial plate for Germany (German) DE
Dial plate for Denmark (Danish) DK
Dial plate English neutral EN
Dial plate for Spain (Spanish) ES
Dial plate for Finland (Finnish) FI
Dial plate for Great Britain (English) GB
Dial plate for Greece (English) GR
Dial plate for Croatia (Croatian) HR
Dial plate for Hungary (Hungarian) HU
Dial plate for Iceland (Icelandic) IS
Dial plate for Italy (Italian) IT
Dial plate for Japan (Japanese) JP
Dial plate for Kazakhstan (Russian) KZ
Dial plate for Lithuania (Lithuanian) LT
Dial plate for Macedonia (Macedonian) MK
Dial plate for Mongolia (Mongolian) MN
Dial plate for The Netherlands (Dutch) NL
Dial plate for Poland (Polish) PL
Dial plate for Romania (Romanian) RO
Dial plate for Russia (Russian) RU
Dial plate for Sweden (Swedish) SE
Dial plate for Slovak Repuplic (Slovakian) SK
Dial plate for Southern Tyrol I2
Dial plate for Ukraine (Ukrainian) UA
Dial plate for Uzbekistan (Russian) UZ
5. Manufacturer's label Code
Logo SIEMENS 06
6. Sensor type and method of connection Code
Flow sensor (without temperature sensors) 0
Sensor Pt100, removable, not mounted in the tube A
Sensor Pt100, removable, mounted in the tube B
Sensor Pt100, removable, mounting in the tube as an
option
C
Sensor Pt100, removable, mounted in the tube within
a pocket
D
Sensor Pt500, removable, not mounted in the tube E
Sensor Pt500, removable, mounted in the tube F
Sensor Pt500, removable, mounting in the tube as an
option
G
Sensor Pt500, removable, mounted in the tube within
a pocket
H
Sensor Pt100, not removable, not mounted in the tube N
Sensor Pt100, not removable, mounted in the tube P
Sensor Pt100, not removable,
mounting in the tube as
an option
R
Sensor Pt100, not removable, mounted in the tube
within a pocket
S
Hardware-dependent features
7. Sensor type Code
Without temperature sensors 00
Type DS, 25 bar/150°C/ M10x1 / length 27,5mm,
cable length 1,5m
0B
Type DS, 25 bar/150°C/ M10x1 / length 27,5mm,
cable length 2,5m
0C
Type DS, 25 bar/150°C/ M10x1 / length 38mm, cable
length 1,5m (only Pt500)
0D
Type DS, 25 bar/150°C/ M10x1 / length 38mm, cable
length 2,5m (only Pt500)
0E
Type PS, 16 bar/150°C/ Ø5,2x45mm, cable length
1,5m
0H
Type PS, 16 bar/150°C/ Ø5,2x45mm, cable length
5m
0J
Type PL, 25 bar/180°C/ Ø6x100mm, cable length 2m 0M
Type PL, 25 bar/180°C/ Ø6x100mm, cable length 5m
(only Pt500)
0N
Type PL, 25 bar/180°C/ Ø6x150mm, cable length 2m 0P
Type PL, 25 bar/180°C/ Ø6x150mm, cable length 5m
(only Pt500)
0Q
8. Power supply Code
Without power supply 0
Standard battery for 6 years A
Battery for 6 years for all applications B
Battery for 11 years (C cell) C
Battery for 11 years E
Battery for 16 years (d cell) F
Battery without printing of the year G
Power supply 24V AC/DC with plug M
Power supply 230V AC with 1.5m cable N
Power supply 230V AC with 5m cable P
Power supply 230V AC with 10m cable Q
Power supply 110V AC with 1.5m cable R
Power supply 110V AC with 5m cable S
Power supply 110V AC with 10m cable T
9. Communication module 1 Code
No module in slot1 0
Analog module in slot1 A
M-Bus module G4 in slot1 B
CL-module in slot1 C
M-bus 30s module in slot1 D
M-bus module G4-MI with 2 pulse inputs N
Pulse module with OptoMOS in slot1 L
Pulse module in slot1 P
10. Communication module 2 Code
No module in slot2 0
Analog module in slot2 A
M-Bus module G4 in slot2 B
CL-module in slot2 C
M-bus 30s module in slot2 D
Pulse module with OptoMOS in slot2 L
Pulse module in slot2 P
Radio module in slot2 R
Radio module with external antenna in slot2 X
11. Data logger Code
Without data logger 0
Data logger with 8 channels 8
12. Calibration / conformity Code
certified acc. to national regulations CL
compliant to MID class 2 M2
compliant to MID class 3 M3
compliant with CEN 1434, class 2 T2
compliant with CEN 1434, class 3 T3
compliant acc. to national regulations TL
13. Energy unit Code
Display: kWh (until qp 10) A

Siemens UH50 Series Specifications

General

Type	Ultrasonic flowmeter
Accuracy	±1% of reading
Communication	HART
Power Supply	24 V DC
Output	4 to 20 mA
Operating Temperature	-20 to +60 °C (-4 to +140 °F)
Resolution	0.001 m/s
