ION module
type
ION module name Hardware port
(device label)
Port setup
register name
Description
Digital
Output
Port A/B/C/D D1–D2 Relay 1–Relay 2
Port A D1–D2
Port B D1–D2
Port C D1–D2
Port D D1–D2
Option module
digital output
Analog Input Port A/B/C/D A1–A4 A1–A4
Port A A1–A4
Port B A1–A4
Port C A1–A4
Port D A1–A4
Option module
analog input
Analog
Output
Port A/B/C/D Q1–Q2 Q1–Q2
Port A Q1–Q2
Port B Q1–Q2
Port C Q1–Q2
Port D Q1–Q2
Option module
analog output
NOTE: When configuring your meter, the configuration interface may show all the possible
ports, regardless of what is physically available on your meter.
For more information, see ION Reference, available on www.usa.siemens.com/pds.
I/O option modules
I/O option modules provide increased digital and analog input/output (I/O) capabilities for your
meter.
These I/O modules can be used to monitor the status of breakers, control analog or digital
transducers, or receive signals that can be interpreted to provide WAGES data for your energy
system. For applications requiring high accuracy, such as energy pulsing to verify accuracy, the
digital output on the meter base is recommended.
NOTE: Your meter’s digital and analog outputs may change state during a firmware upgrade.
Option modules are offline during an option module firmware upgrade; they will not
communicate to the meter and the outputs may change state during the upgrade process.
Your meter’s analog I/O option modules can measure and output either low voltage or current
using standard analog transducers such as 4–20 mA current transducers.
Viewing I/O option module data
View I/O option module data using ION Setup, meter webpages, or the display.
To view option module data using ION Setup:
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
9810 series - User manual Inputs/Outputs
7EN05-0390-08 130
