2.2 SKP15 actuator
7643z73/0817
1
2
3
4
•
Valve stroke display
‚
Indication of operating state (LED)
ƒ
Power supply
„
End switch (valve CLOSED)
Β
Service note!
No spare parts are available for the SKP15 actuator (security regulating unit).
The entire actuator can only be replaced by contacting the burner manufacturer.
