Siemens Washing machine - Removing Transportation Protection Devices; Step-by-Step Device Removal

6
Removing the transportation protection devices
Figure 1 Figure 2.1
Figure 2.2
Figure 2.3
13
1
1
2
2
A
1 Remove the machine from the transport
base. Remove
wedge

(Figure 1 ).
2 Remove the 4 screws

with
a screwdriver
(Figure 2.1 ).
3 Remove transportation protection
devices

: Both bolts

are for this
purpose
(Figure 2.2 ) remove with
a 10 mm or 13 mm spanner (depending
upon model).
Check to see that both plastic inserts
on the connecting carrier have also
been removed.
Refasten the screws

at their original
locations.
4

Close off both holes with the
provided caps

(found in the
accessories package).
( Figure 2.3 )

Before the machine is used for the first time, all transportation protection devices
from the back of the appliance must be removed and stored for any later transport
(i.e., relocation).
