LCD Setting
After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “UP/DOWN” button to
select setting programs. And then, press “ENTER” button to confirm the selection or ESC button to exit.
120A model: Default 60A, 10A~120A Settable
100A model: Default 60A, 10A~100A Settable
80A model: Default 60A, 10A~80A Settable
60A model: Default 60A, 10A~60A Settable
(If Li is selected in program 2, this program can’t be set up)
User-Defined
If “User-Defined” is selected, battery charge voltage and low DC
cut-off voltage can be set up in program 05,06 and 07.
User-Defined 2
Suitable for lithium battery when inverter not communicated with
BMS.
If “US2” is selected, battery charge voltage and low DC cut-off
voltage can be set up in program 05,06 and 07.
Lithium
Only suitable for lithium battery when inverter communicated with
BMS.
The lithium battery BMS communication protocol options:
……
