Power Star W7 Pure Sine Wave Inverter/Charger User’s Manual www.sigineer.com
10
AC MODE
GREEN LED on “AC Input Mode”
INVERTER ON
GREEN LED on “Invert Mode”
FAST CHARGE
Yellow LED on “Fast CHG”
FLOAT CHARGE
GREEN LED on “Float CHG”
OVER TEMP TRIP
RED LED on “Over Temp”
OVER LOAD TRIP
RED LED on “Over Load”
CHARGING
GREEN LED on “Ready Position”
Please refer to ‘Indicator and Buzzer’ for the detailed information.
2.5.8 Audible Alarm
The inverter also gives audible alarms when the following situations occur.
Battery Voltage Low
Inverter green LED Lighting, and the buzzer beep 0.5s every 5s.
Battery Voltage High
Inverter green LED Lighting, and the buzzer beep 0.5s every 1s,
and Fault after 60s.
Invert Mode Over-Load
(1)110%<load<125%(±10%), No audible alarm in 14 minutes,
Beeps 0.5s every 1s in 15
th
minute and Fault after 15 minutes;
(2)125% <load<150%(±10%), Beeps 0.5s every 1s and Fault after 60s;
(3)Load>150%(±10%), Beeps 0.5s every 1s and Fault after 20s;
Over Temperature
Heat sink temp. ≥105ºC(221℉), Over temp red LED Lighting, beeps
0.5s every 1s;
2.5.9 FAN Operation
For 600W-1KW models, there is one multiple controlled DC fan.
The DC fans are designed to operate according to the following logic:
Condition
Enter Condition
Leave condition
Speed
HEAT SINK
TEMPERATURE
T ≤ 60℃(140℉)
T > 65℃(149℉)
OFF
65℃(149℉)≤ T < 85 ℃(185℉)
T ≤ 60℃(140℉) or T ≥ 85℃(185℉)
50%
Line Mode
Inverter Mode
Fast Charge
Float Charge
Alarm
Over Temp
Over Load
Power Saver
Battery Type Selector
