SIGLENT SDG2042X Service Manual

SDG2000X_ServiceManual_SM0202X-E01B.doc
15
DC Characteristics
Parameter
Min.
Typ.
Max.
Unit
Condition
Range
-10
10
V
HiZ load
-5
5
V
50 Ω Load
Accuracy
±(1%+2 mV)
HiZ load
Output Characteristics
Parameter
Min.
Typ.
Max.
Unit
Condition
Range
(Note 1)
2m
20
Vpp
≤20 MHz, HiZ load
2m
10
Vpp
>20 MHz, HiZ load
Accuracy
±(1%+1mVpp)
10 kHz Sine, 0 V offset,
Amplitude
flatness
-0.3
+0.3
dB
0~100 MHz (Included), 50 Ω
Load, 2.5 Vpp, compare to 10
KHz Sine
-0.4
+0.4
dB
100~120 MHz (Included), 50 Ω
Load, 2.5 Vpp, compare to 10
KHz Sine
Output
impedance
49.5
50
50.5
Ω
10 KHz Sine
Output
current
-200
200
mA
Crosstalk
-60
dBc
CH1 - CH2, and CH2 - CH1
Note 1: The specification will be divided by 2 when applied to a 50 Ω Load.
Modulation Characteristics
AM
Parameter
Min.
Typ.
Max.
Unit
Condition
Carrier
Sine, Square, Ramp, Arb
Modulation
Source
Internal/External
Modulating
wave
Sine, Square, Ramp, Noise, Arb
Modulation
depth
0
120
%
Modulation
frequency
1m
1M
Hz
While modulation source is
“Internal”
FM
Parameter
Min.
Typ.
Max.
Unit
Condition
Carrier
Sine, Square, Ramp, Arb
Modulation
Source
Internal/External
Modulating
Sine, Square, Ramp, Noise, Arb
