Sigma Controls MYRIAD DPC User Manual

4
SPECIFICATIONS:
 ANALOG INPUT (1 ea.) (A second AI is available when backup sensor is enabled)
Analog, 4/20MA, 0-5V, 1-5V, 0-10VDC, isolated with common negative, +-0.1%
accuracy.
 DIGITAL INPUTS (7 ea.) (7 additional DIs are available with the Aux PCB)
Digital 10-30VDC
 ANALOG OUTPUT: (4 ea.)
Analog, with common negative 0-20MA, 4/20MA, 0-5V, 0-10V (voltage output requires a
resistor).
 DIGITAL OUTPUTS: (4 ea.) (Horn output available on Aux PCB)
Opto isolated, solid state, open collector, 100MA 30VDC max.
 RELAY OUTPUTS: (4 ea.)
SPDT, Form ‘C’ 5A Relay
 DISPLAY:
LCD, 128 X 32 pixel bitmapped graphic display
 LOOP POWER:
24VDC regulated output, 100MA max.
 5 USER KEYS:
Up, Down, Left, Right, Enter
 ACCURACY:
0.1% of calibrated span
 LOCKOUT:
User password, user configurable
 INPUT IMPEDANCE:
Voltage 100K, current 100 OHMS
 POWER:
120VAC (230VAC available)
 ENVIRONMENTAL:
Operating, 0-65° C
Storage, -40° -80° C
R.H., 0-90% non-condensing
 ENCLOSURE:
¼ DIN, ABS plastic 96 X 96 X 124MM or Nema 4X wall mount 12 x 8 x 8 inches
