FEATURES:
Microprocessor Based
Graphic LCD Display
5 Function Keys
Isolated 24VDC Sensor Power
4/20MA, 1-5V, 0-5V, 0-10VDC Programmable input
2 Analog Input
4 Analog Outputs
7 Digital Inputs (7 additional DIs are available with the Aux PCB)
4 Digital Outputs (Horn output available on Aux PCB)
4 Form ‘C’ Relay Outputs
Fully User Programmable in English
2 Ea. RS485 Ports (Programming and SCADA)
CPU Activity Monitor
P.I.D. Control (optional selection)
WIRING DETAIL
Inputs, see Dwg # 07-105
Outputs, see Dwg # 07-105
The range selector switches located on the bottom of the circuit
board are factory set. If a field change of input type is required see
Appendix ‘A’. Do not apply an input signal that is not coordinated with
range switches or the unit may be damaged.
CAUTION
!
All electrical wiring must be in accordance with all local state and national
codes that apply.
Do not exceed the rated current of the D.C. power supply (100MA) or the
form ’C’ relay outputs (5A/240VAC resistive).
WARNING
Hazardous voltages are present within the enclosure. Installation or
service should only be carried out by trained personnel.
!
