8. SETUP MODE
Setup mode is entered by placing the mode switch in the right most position.
Setup mode is used to modify operational parameters of the chamber. When first
entering Setup mode, the digital display should display:
f-0 n (n = 1 to 10)
This first display indicates the setting for field 0. There are thirty parameter
fields which can be modified. Table 8.1 shows the meaning of each field and the
values each field can be assigned.
T A B L E 8.1
Field
#
Field Purpose
Permitted Field
Values
Factory Setting
0
PID controller, Proportional term
Controller gain, P term, number=°C from
setpoint where controller will use full on
control
1 - 10
4 - 7
Default=4
1 Number of Probes installed 1 - 2 1
2
Remote communication port select
0 = EIA-232 1 = IEEE-488
0 - 1 1
3
EIA-232 port baud rate
1=300 2=600 3=1200 4=2400
5=4800 6=9600 7=19,200
8=38,400
1 - 8 6
4 EIA-232 port data bits 7 - 8 8
5 EIA-232 port stop bits 1 - 2 1
6
EIA-232 port parity enable
0=disabled 1=enabled
0 - 1 0
7
EIA-232 port parity type
0=even 1=odd
0 - 1 0
8
EIA-232 port echo
0=disabled 1=enabled
0 - 1 1
9 IEEE-488 port primary address 0 - 30 1
