32 I ASSEMBLY
3.1 EOX
®
REMOTE 500
− Open the clamp of the EOX
®
REMOTE 500 and place it on the handlebar (22.2 mm).
− Close the clamp and align the EOX
®
REMOTE 500 ergonomically fi t.
− Take care that the cable fi ts the intended guidance at the inner side of the clamp.
− Tighten the screw (Allen Bolt 3mm) (for tightening force please refer to table below).
− Connect the plug (purple) with the cable from your E-Bike.
