CCP 621 C-DIAS PROSESSOR MODULE
Page 14 27.03.2020
Applicable Connectors
USB Device: 5-pin, type Mini-B
USB Host: 4-pin, type A
Ethernet: 8-pin, RJ45
VARAN: 8-pin, RJ45
CAN Bus: 6-pin Weidmüller plug, B2L3, 5/6
Supply: 2-pin Phoenix plug with screw terminal technology MC 1.5/ 2-ST-3.5
2-pin Phoenix plug with spring terminal FK-MCP 1.5/ 2-ST-3.5
The complete C-DIAS CKL 031 connector set with spring terminals is available from
SIGMATEK under the article number 12-600-017.
S-DVI Cable
0.3 m
2 m
3 m
3.5
5 m
7 m
10 m
15 m
Art.No.: 05-950-003
Art.No.: 05-950-020
Art.No.: 05-950-030
Art.No.: 05-950-035
Art.No.: 05-950-050
Art.No.: 05-950-070
Art.No.: 05-950-100
Art.No.: 05-950-150
NOTE:
Connecting the S-DVI cable under voltage can damage the S-DVI interface; it is not
hot-plug capable.
