29
07.09
SIGNODE BXT2
53 428775 Tooth plate Placa dentada 1
54 428776 Pan head screw Tornillo 1
55 428777 Strap stop, front 13mm Limitador del fl eje 13mm 1
56
57
59 428778 Pawl shaft
Trinquete 1
60 428779 Pawl wheel Bloqueo de rueda 2
61 428889 Retaining ring, Ø5 Arandela de fi jación 1
62
64 428780 Bolt Tornillo 1
65 428781 Blocking pawl Trinquete 1
66 428782 Retaining ring, Ø8 Arandela de fi jación 2
67
68
70 428783 Bolt Tornillo 1
71 428784 Spacer disk, Ø5/10x0.2 Arandela 1
72 428785 Reset cam Cuva 1
73 428786 Set screw, M4x10 Tornillo prisionero 1
74 428787 Retaining ring, Ø4 Arandela de fi jación 6
75 428788 Support micro switch Ayuda 1
76 428890 Panhead screw, M4x10 Tornillo 4
77 428789 Welding cables Cables de la soldadura 1
78
79
81 428790 Compression spring Resorte opresor 1
82 428791 Ball, Ø8 Bola 1
83 428792 Compression spring Resorte opresor 1
84 428793 Balll, Ø9 Bola 1
85 428794 Set screw, M12x10 Tornillo prisionero 1
86 428795 Set screw, M8x6 , Tufl ok Tornillo prisionero 1
87
88
89 428796 Rocker lever complete Palanca de balacín completo 1
90 428797 Toothed lever Palanca dentada 1
91
92
95 428798 Motor complete Motor completo 1
96 428799 Motor support complete Ayuda del motor completo 1
97
98
99 428800 Counter sunk screw, M3x8 Torn. cabeza. perd. 6
100 428801 Spacer disk, Ø4/8x0.1 Arandela 3
101 428802 Shoulder screw, M5 Tornillo de hombro 2
102 428803 Cylinder screw, M4x30 Tornillo cilíndrico 1
103 428804 Cables tensioning Tensir de los cables 1
104 428805 Panhead screw, M2x10
Tornillo 1
105
106
108 428806 Ball bearing, Ø30/37x4 Rodamiento ran. 1
109 428807 Excentric cam Árbol de excéntricos 1
110 428808 Planetary wheel, 3st step Engrane planetario 3. Grado 3
111 428809 Spacer disk, Ø12/24x0.2 Arandela 1
112 428810 Carrier complete 2st step 1
113
114
116 428811 Planetary wheel, 2st step Engrane planetario 2. Grado 6
117 428812 Spacer disk, Ø6/12x0.2 Arandela 2
118 428813 Carrier complete 1st step Portador completo 1. Grado 1
119
120
124 428814 Ring Anillo 1
125 428815 Cover motor support Envoltura del motor compl. 1
127 428891 Belt wheel complete Rueda de la correa 1
128
129
130 428816 Starting disk Comenzar el disco 1
131 428817 Ball bearing, Ø15/24x5 Rodamiento ran. 2
132 428818 Bevel wheel complete Piñones cónicos completo 1
133
134
135 428819 Spacer ring, Ø15/18x2.9 Arandela 1
136 428820 External retaining ring, Ø15 Arandela de fi jación 1
137
138
140 428821 Switching cam Leva de la conmutación 1
141 428822 Spacer, Ø5/10x0.1 Arandela 2
142 428823 Bolt Tornillo 1
143 428824 Bolt Tornillo 1
KEY PART
#
DESCRIPTION QTY KEY PART
#
DESCRIPTION QTY
