Signode HSM 3000 - Table of Contents

10.19
HSM 3000
3
TABLE OF CONTENTS
Page
1 Description 4
2 Safety instructions 5
3 Technical data 7
4 Description 8
4.1 Design 8
4.2 Machine description 9
4.2.1 Operating elements 10
4.2.2 Description of operating sequence 12
4.2.3 Signal exchange 13
4.2.4 Mode of operation 13
5 Installation and putting into service 14
5.1 Installation 14
5.2 Power supply 14
5.3 Signal exchange 14
5.4 Putting into service 14
6 Operating instructions 15
6.1 Switchon/o󰀨machine 15
6.2 Mode of operation „Manual“ 16
6.2.1 Programming strapping positions
„Teach-In“ 19
6.3 Information library 20
6.4 Messages and malfunctions 22
Page
6.5 Working in danger area 23
6.5.1 Working below carriage 23
6.6 Replace strap coil 24
6.7 Elimination of faults (Operator) 25
6.7.1 Out of strap 25
6.7.2 Strap misfeed 25
6.7.3 Collision guard 25
6.7.4 Inverter drive malfunction 26
6.8 Check of seal 26
7 Preventive maintenance 27
7.1 Preventive maintenance schedule 27
7.2 Functionalchecksofassembliesa󰀨ecting
safety 28
7.3 Checkguideaps 28
8 Corrective maintenance 29
8.1 Elimination of faults 29
8.2 Swivel strapping head 90° Service position) 29
8.3 Replacing strapping head 30
8.4 Changing strap quality and strap
dimensions 30
8.5 Changing/adjusting toothed belt 30
8.6 Ordering spare parts 31
9 Dismantling and disposal 32
