Signode HSM 3000 - Technical Data

10.19
HSM 3000
7
3 TECHNICAL DATA
Strap feed and
take-up speed 6.7m/s(263″/s)
Tensioning force
H 3000 Fully adjustable: 300–3000 N
H 3000-L Fully adjustable: 300–1200 N
Tensioning stroke Endless
Stroke velocity
vertical approx. 0.16 m/s (6.2“)
Stroke velocity
horizontal approx. 0.10 m/s (3.9“)
Strapping time approx. 8 s (without vertical
movement)
Seal joint Friction welded
Weight approx. 900 kg (1984 lbs.)
Power supply 3 x 400 V, 50 Hz, 3 P + E +/- 5%
Control voltage 24 VDC
Pneumatic
air pressure (optional) 4 –6 bar (58–87 psi)
Ambient
temperature 0–40 °C
Relative
humidity Up to 90 %
Dimensions of
strap coil Core- ø 405 mm (15.8“)
Extern.- ø approx. 600 mm (23.6“)
Width max. 160 mm (6“)
For machine dimension see dimensioned
drawing. For more technical data see opera-ting
instructions „H 3000“ and dispenser „OR-A 635 E/OR-A 636
E/OR-A 637“
dB
N
Hz
VA
kg
3.1 PLASTIC STRAP
Thismachine,machinenumber.....................................hasbeenttedatthefactorywith:
 PET-  PP-strap in automatic quality
for strap width of .................... mm.
H 3000:
Order no Strap width Used strap thickness
PP (mm) PET (mm)
min. max. min. max.
2166.440 12/13 mm (
1
/
2
″) 0.71 0.90 0.51 0.95
2166.540 16 mm (
5
/
8
″) 0.65 0.90 0.50 0.95
H 3000-L:
Order no Strap width Used strap thickness
PP (mm) PET (mm)
min. max. min. max.
2165.940 9/10 mm (
3
/
8
″) 0.65 0.80 0.35 0.60
2165.440 12/13 mm (
1
/
2
″) 0.65 0.70 0.35 0.50
CAUTION
Adi󰀨erentstrapqualityor
di󰀨erentstrapdimensions
can lead to strap feed or
machine malfunction. For
the change of strip quality
and strip dimension, see
chapter 8.4.
