Signode MCD-710 - User Manual

Questions and Answers

S
Stacey LeeAug 16, 2025
What to do if the motor fails to start on my Signode MCD-710 Packaging equipment?
- D
  Daniel ToddAug 17, 2025
  If the motor on your Signode Packaging equipment fails to start, there are several things you can check: * First, see if the overload relays have tripped. If they have, reset the overload button located in the control box. * Second, check for voltage at the motor terminal block. Look for blown fuses, broken or loose wires, or disconnected prongs. * If neither of those solutions work, the motor may be defective and require replacement.
V
Veronica DyerAug 19, 2025
Why does my Signode Packaging equipment pull up tension but hesitate before welding?
- L
  Lisa WareAug 19, 2025
  If your Signode Packaging equipment pulls up tension but hesitates before welding, it could be due to a few reasons: 1. One or both traction wheels might be slipping. Check, clean, or replace the traction wheels as needed. Ensure the strap is dry, cutting off any oily sections or replacing the whole coil. 2. The tension might be too high. Try reducing the tension. 3. The main drive belt could be slipping. Increase the tension on the belt.
E
ellisjoyceAug 27, 2025
Why is there hesitation during welding with my Signode Packaging equipment?
- C
  cristinagarciaAug 28, 2025
  Hesitation during welding with your Signode Packaging equipment can stem from several issues: 1. Lack of lubrication: Lubricate the vibrator shaft bushings and eccentric bearing. 2. Worn belts: Check and replace the belts if necessary. 3. Damaged eccentric bearing: Inspect the bearing and replace it if damaged. 4. Low voltage: Check and correct any voltage issues.
P
Paul SanchezAug 30, 2025
Why does my Signode MCD-710 Packaging equipment fail to stop in the home position?
- R
  Russell BoydAug 30, 2025
  If your Signode Packaging equipment fails to stop in the proper home position, here are a few things to investigate: * The idler gear roller clutch might be slipping. Replace the idler gear. * The micro-switch might be improperly adjusted. Check for proper adjustment of the actuator arm. * The Belleville washers might be worn. Replace the washers.
V
Virginia HendersonSep 2, 2025
What causes the strap to escape the chute and continue feeding on Signode MCD-710 Packaging equipment?
- L
  larrygreeneSep 2, 2025
  If the strap escapes the chute and continues to feed until the machine is shut off, consider these possibilities: 1. The machine might not be in the home position. Reposition it to the home position. 2. There could be kinks in the strap. Cut off the kinked section of the strap. 3. The gates might be stuck open. Check the gates for sufficient spring pressure and proper operation.
T
Todd AlvaradoSep 4, 2025
What to do if Signode MCD-710 continues to run in weld direction?
- L
  lori13Sep 5, 2025
  If your Signode Packaging equipment continues to run in the weld direction, consider the following: 1. The micro-switch might be improperly adjusted. Readjust the micro-switch. 2. The switch arm could be stuck against the machine cover. Loosen the four head mounting screws and shift the head to gain clearance.
K
Keith JordanSep 7, 2025
Why does the strap escape from the stretch-out box during take-up on my Signode Packaging equipment?
- J
  Jasmine JonesSep 8, 2025
  If the strap escapes from the stretch-out box during take-up, it could be due to: 1. Too much strap being taken up. Check the package to chute ratio, ensuring it does not exceed 5:1. 2. The strap not accumulating in the stretch-out box. If the strap is too stiff, add a strap snubber kit to the stretch-out box.
R
raymondmarcusSep 10, 2025
Why does my Signode MCD-710 Packaging equipment perform double welding?
- A
  aandersonSep 10, 2025
  If your Signode Packaging equipment immediately goes into another weld cycle after completing one, it is possible that the drop-out arm is stuck in the open position. Make sure the drop-out arm is free and its pivot pin is lightly lubricated. Be careful not to get lubricant on the tension wheel.
M
Max MendozaSep 13, 2025
What causes low or erratic tension in Signode Packaging equipment?
- C
  Cynthia HoffmanSep 13, 2025
  Low or erratic tension can be caused by the slip clutch being set too high. Adjust the slip clutch nut.
L
Lauren HoldenNov 21, 2025
How to fix a Signode MCD-710 Packaging equipment that runs but doesn't fill the chute?
- A
  Anthony BrownNov 21, 2025
  If your Signode Packaging equipment continues running in the feed direction but fails to fill the chute, consider the following: 1. The feedwheel might be slipping. If it is worn, replace it. 2. The strap may be stuck around the dispenser. Check the dispenser for obstructions. 3. The pinch rollers could be stuck. Inspect the pinch rollers and eccentric shaft, lubricating or replacing them as needed. 4. You might be out of strap. Reload the dispenser and machine, ensuring the strap chute is empty before reloading. 5. The slip clutch might be set too low. Check the slip clutch setting and adjust the slip clutch nut if needed. 6. There might be a jam in the traction wheel area. Try pulling the strap out, cutting off any damaged sections, and reloading. If you cannot pull it out, remove...

Summary

Safety Instructions

Operating Instructions

Maintenance Procedures

Moving Machine Parts Safety

Machine Installation Guide

Personal Protection Equipment

Lockout;Tagout Procedures

Introduction to Signode MCD

Electrical Disconnect and Lock-Out

Machine Specifications

Installation and Major Components

Principles of Operation

Loading and Feeding Strap

Step-by-step guide for loading and feeding strap into the machine.

Tensioning and Welding Process

Details on the strap tensioning and welding cycle processes.

Welding Without Bundle Procedure

Procedure and consequences of welding without a bundle in place.

Setting Machine Home Position

Instructions on how to set the machine to its home position.

Feed Cycle Explained

Final Tension Cycle Explained

Slack Removal Cycle Explained

Maintenance and Lubrication Schedule

8 Hour Inspection Tasks

Daily inspection tasks for the strapping machine.

40 Hour Inspection Tasks

Routine maintenance checks required every 40 hours of operation.

200 Hour Inspection Tasks

Periodic maintenance checks required every 200 hours of operation.

Lubrication Procedures

Recommended lubricants and procedures for machine lubrication.

Cleaning Considerations

Important considerations for cleaning the strapping machine.

Electrical Sequence (No Operatorless Interlock)

General Start-Up Procedure

Initial step to start the machine by engaging the E-Stop.

Feed Cycle Electrical Sequence

Detailed electrical sequence for the strap feed cycle.

Tension Cycle Electrical Sequence

Detailed electrical sequence for the tensioning cycle.

Weld Cycle Electrical Sequence

Detailed electrical sequence for the welding cycle.

Pre-Feed Cycle Electrical Sequence

Detailed electrical sequence for the pre-feed cycle.

MCD Electrical Schematic

Electrical Sequence (Operatorless Interlock)

General Start-Up Procedure

Initial step to start the machine by engaging the E-Stop.

Feed Cycle Electrical Sequence

Detailed electrical sequence for the strap feed cycle.

Tension Cycle Electrical Sequence

Detailed electrical sequence for the tensioning cycle.

Weld Cycle Electrical Sequence

Detailed electrical sequence for the welding cycle.

Pre-Feed Cycle Electrical Sequence

Detailed electrical sequence for the pre-feed cycle.

Operatorless Interlock Contacts

Information on optional contacts for operatorless interlock systems.

MCD Electrical Schematic (Operatorless)

Control Panel Assembly Components

Control Panel Assembly Diagram

Machine Parts List

Part Assembly Diagrams

Welding Assembly Parts List

Part Removal and Replacement: Vibrator;Gripper

Part Removal and Replacement: Cutter

Micro-Switch Adjustment Procedures

Strap Transport Mechanism Parts List

Part Removal and Replacement: Traction Wheels

External Assembly Parts List

Optional Strap Snubber Kit

Part Removal and Replacement: Drive Belt

Micro Switch Adjustment Details

2 LS: Drop-Out Arm Switch Adjustment

Adjustment procedure for the drop-out arm micro switch.

1 LS: Cam Shaft Switch Adjustment

Adjustment procedure for the cam shaft micro switch.

1 LS Internal Switch Adjustment

Specifics on internally adjusting the 1LS micro switch.

1 LS Adjustment Procedures

Step-by-step guide for performing 1LS micro switch adjustments.

1 LS Adjustment Diagram

Covers, Signs, and Dispenser Brackets

Dispenser and Bracket Assembly Diagram

Recommended Spare Parts List: Head

Troubleshooting: Machine;Head Issues

#1 Symptom: No Weld

Troubleshooting steps when the machine fails to weld.

Troubleshooting: Machine;Head Issues (Continued)

#2 Symptom: Strap Escapes Chute

Troubleshooting steps for strap escaping the chute.

#3 Symptom: Hesitation During Welding

Troubleshooting steps for hesitation during the welding process.

#4 Symptom: Improper Home Position Stop

Troubleshooting for improper home position stopping of the machine.

#5 Symptom: Motor Fails to Start

Troubleshooting steps when the machine motor fails to start.

Troubleshooting: Machine;Head Issues (Continued)

#6 Symptom: Feed Direction Issues

Troubleshooting for feed issues where the chute isn't filled.

#7 Symptom: Tensioning Before Weld

Troubleshooting for tensioning issues before welding.

#8 Symptom: Continuous Weld Direction Run

Troubleshooting for the machine running continuously in the weld direction.

Troubleshooting: Machine;Head Issues (Continued)

#9 Symptom: Double Welding

Troubleshooting steps for instances of double welding.

#10 Symptom: Strap Escapes Stretch-Out Box

Troubleshooting for strap escaping the stretch-out box.

#11 Symptom: Low or Erratic Tension

Troubleshooting for low or erratic strap tension.

Modular Chute System Overview

Chute Sizes by Part Number

Table listing chute sizes and corresponding part numbers.

Modular Chute Assembly

Gate Tension Adjustment

Modular Chute System Installation

Chute Installation Steps

Steps for installing the modular chute system onto the machine.

Chute Assembly Parts List

Variable Chute Components

18 High Chutes Components

Parts for 18" high chute configurations.

24 High Chutes Components

Parts for 24" high chute configurations.

30 High Chutes Components

Parts for 30" high chute configurations.

Modular Chute System Components (Continued)

36 High Chutes Components

Parts for 36" high chute configurations.

48 High Chutes Components

Parts for 48" high chute configurations.

60 High Chutes Components

Parts for 60" high chute configurations.

72 High Chutes Components

Parts for 72" high chute configurations.

Chute Assembly Diagram

Modular Chute System Diagrams

Optional Chute Support Installation

Troubleshooting: Modular Chute Issues

#1 Symptom: Strap Fraying;Tangled Wheels

Troubleshooting for strap fraying and tangled wheels.

#2 Symptom: Strap Snags at Chute Corners

Troubleshooting for strap snagging at chute corners.

Troubleshooting: Modular Chute Issues (Continued)

#3 Symptom: Strap Trapped in Chute

Troubleshooting for strap trapped in chute gate or guide.

#4 Symptom: Strap Escapes Chute During Feed

Troubleshooting for strap escaping chute during feed.

#5 Symptom: Strap Bubbling Out of Chute Entry

Troubleshooting for strap bubbling out of chute entry.

#6 Symptom: Strap Fails to Release from Head

Troubleshooting for strap failing to release from head on high packages.

DF1-12 D Dispenser Operation Instructions

Dispenser Operation and Adjustments

DF1-12 D Dispenser Parts List

DF1-12 D Dispenser Parts Diagram

DF1-12 D Dispenser Conversion Instructions

Left Hand Strap Pay-Off Conversion

Steps to convert the dispenser for left-hand strap pay-off.

MCD Machine Options Overview

Signode MCD-710 Specifications

General

Model	MCD-710
Category	Packaging equipment
Seal Type	Friction weld
Type	Strapping machine
Strap Thickness	0.4 - 1.0 mm
