Why don't the strap drive and camshaft move on my Signode Packaging equipment?
If the strap drive and the camshaft of your Signode Packaging equipment do not move while the motor runs, it could be due to the small clutch Y37 (15 Nm at transmission 100.36) not being activated, or one or both clutches (Y22, Y37) not being activated. Inspect the fuse, fast switching device, and cable terminals of the transmission to resolve this.
What to do if there is no strap feed in my Signode Packaging equipment?
If your Signode Packaging equipment has no strap feed, it could be because strap switch B102 stays activated or strap switch B183 is not activated. Check the switch actuator and actuator lever. Also, ensure the ejector gate isn't jammed and check the function of the proximity switch.
Why is the strap not being cut off correctly in my Signode Packaging equipment?
If the strap is not being cut off correctly in your Signode Packaging equipment, it might be due to a large tolerance between the cutter blade and gripper. Try reducing the gripper tolerance by readjusting the setting screws. Ensure plungers (grippers) move freely! Alternatively, insert a spacer between the cutter blade and vibrator support, making sure plungers (grippers) move freely!
How to fix incomplete strap feed in Signode Packaging equipment?
If you're experiencing incomplete or improper strap feed with your Signode Packaging equipment, it might be caused by a strap feed disturbance into the head or the strap hitting the strap guide. Inspect the dispenser, accumulator, and pulleys, and check the strap guide.
What to do if the strap tip hits the cutter blade on my Signode Packaging equipment?
If, after completing a strapping cycle, the strap tip hits the cutter blade when re-entering on your Signode Packaging equipment, the vibrator support might be jammed. Remove and clean it. Alternatively, the spring in the pressure pad might be jammed or missing; free the pressure pad or insert the spring.
Why is the strap tip being pulled out during take-up on my Signode Packaging equipment?
If, during take-up, the strap tip is being pulled out of the head while the camshaft stops shortly before point 4 on your Signode Packaging equipment, the gripper support might be set too tight. Readjust the contact pressure. Another cause may be that the teeth of the clamping pad are worn, in which case you should replace it.
Why does the strap drive not move and make noise on my Signode Packaging equipment?
If the strap drive does not move, you hear a squeaking noise, and the camshaft stops shortly before point 4 on your Signode Packaging equipment, the large clutch Y22 in the transmission may be worn out. Alternatively, the strap tension might be set too high, so adjust the strap tension. Another possible cause is that the guide shaft for the Belleville washers gets stuck; grease or oil the guide shaft and check it for wear.
Why does my Signode Packaging equipment feed multiple strap layers?
If your Signode Packaging equipment is feeding more than one layer of strap into the chute and stops after the time delay setting, it is likely due to a malfunction of the strap stop limit switch B102. Inspect the limit switch and replace or adjust it as needed.
Why won't the strap tension on my Signode Packaging equipment?
If the feed wheel rotates in the take-up direction but does not tension the strap, and the camshaft stops shortly before point 4 on your Signode Packaging equipment, the feed wheel ring might be slipping. Clean the feed wheel ring or replace it. Also, the pre-tension spring adjustment might be too low, so readjust it.
Why is there too much strap overlap with my Signode Packaging equipment?
If you are experiencing too much strap overlap, where the strap feeds too far on your Signode Packaging equipment, the time may have been set too long. The time setting must be changed by reprogramming the CPU.
Safety precautions for operating the Signode strapping machine.
Safety precautions for servicing the Signode strapping machine.
Further safety advice for machine operation and modification.
Diagram identifying key components of the strapping head.
Step-by-step guide for inserting the strap into the head.
Procedure for opening the pusher for inspection and cleaning.
Steps to disengage the back-up roller chain for maintenance.
How to adjust strap tension using the adjustment screw.
Explanation of proximity switches for strap stop and shutter.
Function of proximity switches for pusher and speed tension.
Function of the B106 proximity switch for final tension.
Step-by-step process for strap tensioning, sealing, and cutting.
Purpose and general overview of the strapping head.
Key technical data for the AK200-HDX strapping head.
Overview of the strapping head's operational steps and functions.
Detailed explanation of the strapping head's cycle steps.
Explanation of the camshaft display indicator positions.
Comments on the function of the planetary gear drive.
Guidelines for daily, weekly, monthly, and annual maintenance.
Procedures for safely removing and replacing machine parts.
Instructions for re-adjusting gripper, loop grip, and vibrator.
Adjusting welding time and cool-off time for joint strength.
Adjusting strap tension and roller chain tension.
Information on proximity switch settings and re-adjustments.
Common issues and remedies for strap feeding problems.
Common issues and remedies for strap take-up problems.
Common issues and remedies for strap tensioning problems.
Common issues and remedies for sealing and cut-off processes.
List of recommended spare parts for AK200-HDX-32 MM.
List of remote spare parts for AK200-HDX-32 mm.
Details on conversion kits for AK200-HDX strap sizes.
Overview of sub-assembly drawings and parts lists.
Comprehensive parts list for the AK200-HDX strapping head.
Parts list for the AK200-HDX sealing mechanism.
Parts list for the AK200-HDX transmission.
Parts list for the AK200-HDX strap drive.
Parts list for the AK200-HDX brake.
Parts list for the AK200-HDX intermediate shaft.
Parts list for the AK200-HDX camshaft.
Parts list for the AK200-HDX camshaft brake.
Parts list for the AK200-HDX spring assembly.
Parts list for the AK200-HDX insert guide with spring.
Parts list for the AK200-HDX strap guide wedge.
Parts list for the AK200-HDX air blowing device.
General| Model | AK200HDX-19 |
|---|---|
| Category | Packaging equipment |
| Strap Width | 19 mm |
| Sealing Method | Friction weld |
| Power Source | Pneumatic |
| Sealing | Friction weld |
| Strap Type | Polyester |
| Weight | 16 lbs |
| Air Pressure | 6.0 bar |
