Signode AK200HDX-19 - Basic Operating Instructions; Machine Overview Diagram

1
SIGNODE AK200-HDX
Basic Operating and Adjustment Instructions
Strap stop
switch
Holding brake
cam shaft
Transmission
Drive motor
Drive motor
Strap entry chute
Weld Motor
Pusher
(cover plate)
Sealing
Mechanism
Air blowing
device
Strap guide wedge
Feed wheel
Back-up
roller chain
Drive motor
Disk washer
with aux. spring
Sealing punch polder
Cam shaft
