6. Product view
6.1. Front side
1
USB cable (permanently attached)
4
Ergonomic pen with replaceable cartridge
2
Liquid Crystal Display (LCD) with
a special protective surface
5
Cord (attached to the device and pen)
3
Status LED
6.2. Back side
1
Pen holder
5
Device designation
2
Cord (attached to the device and pen)
6
Item number
3
USB cable (permanently attached)
7
Hardware revision number
4
Mounting holes for holders
8
Barcode with unique serial number
