AP05
Identification English
AP05 · Date 25.09.2018 · Art. No. 88847 · Mod. status 316/18
23
External magnetic fields
Failures and data loss occur if strong magnetic fields influence the internal
measuring system.
` Protect the position indicator from impact by external magnets.
3 Identification
Please check the particular type of unit and type number from the identifi-
cation plate. Type number and the corresponding version are indicated in
the delivery documentation.
e. g. AP05-0023
variant number
type of unit
4 Installation
Position indicator failure/damage to the connector insert
The connector insert in the device will be damaged if the torque applied to
the mating connector is too high.
` Tighten the mating connector using the torque-limiting wrench of
the relevant connector vendor. Pay attention to the tightening torque
specified by the manufacturer.
` Using a torque wrench tighten the mating connector(see chapter 8.1,
8.2 and 8.3). Manufacturer's recommendation of a suitable torque can
be obtained on request. Tightening torque: 0.4Nm
` Do not transmit torque/forces into the device via the housing of the
mating connector or cable. Tighten only the securing nut of the mat-
ing connector.
Position indicator failure/mechanical stress on the mating connector
Excessive external force impacting on the mating connector will damage
components of the position indicator and/or the mating connector.
` Protect the mating connector from impact of external forces.
` In areas where the impact of forces caused by the operating personnel
or dropping objects cannot be excluded attach an eective support of
the mating connectors against the machine body.
CAUTION
WARNING
WARNING
