AP05
Technical data English
AP05 · Date 25.09.2018 · Art. No. 88847 · Mod. status 316/18
36
9 Technical data
Mechanical data Additional information
Shaft plastic
Housing reinforced plastic plug thread / PE connection
metal
Color black, RAL 9005
Clamping ring stainless steel
Speed ≤500rpm
Cable sheath PUR EX15 type of connection
Cable bending radius ≥30mm permanently laid
Electrical data Additional information
Operating voltage 24VDC ±20% reverse polarity protected
Current consumption ~30mA
Battery service life ~8 year(s)
Display/display range 5-digit LCD 7-segment,
~6mm height
decimal points, 2 rows, spe-
cial characters (LED backlit red/
white)
Special character arrow clockwise, arrow coun-
ter-clockwise, incremental
dimension, battery
Status display 2x two-color LED (red/green) position status, configurable
Keys incremental measurement
function, parameterizing,
resetting
Bus connection RS485; CANopen no galvanic isolation
Type of connection 2x M8 plug connector
(A-coded)
4-pole, 1x socket, 1x pin
grounding via flat connector
6.3mm
System data Additional information
Scanning magnetic
Resolution 720 increments/revolution displayed value/revolution freely
configurable
Measuring range ≤932067 revolution(s) coded
Ambient conditions Additional information
Ambient temperature 0 … 60°C
Storage temperature -20 … 80°C
