DE04 DE04/1 DE10 · Date 10.12.2012 · Art. No. 84260 · Mod. status 384/12
18
2.4 Basic safety information
Danger of explosion
` Do not use the position indicator in explosive zones.
Rotating parts
Bruising, rubbing, abrasing, seizing of extremities or clothes by touching
during operation any rotating parts as for example clamping ring, torque
support or hollow shaft.
` Prevent people from access by installing protective facilities.
External magnetic fields
Failures and data loss occur if strong magnetic fields influence the internal
measuring system.
` Protect the position indicator from impact by external magnets.
3 Identification
Please check the particular type of unit and type number from the identifi-
cation plate. Type number and the corresponding version are indicated in
the delivery documentation.
e. g. DE04-0023
version number
type of unit
4 Installation
4.1 Mechanical mounting
Destruction of main bearings
Improper installation (e. g. tension on the driving shaft) causes addi-
tional heat development and destruction of the position indicator in the
long term.
` Ensure a low shaft and angle oset between shaft and accommoda-
tion bore by applying appropriate manufacturing methods (see Fig. 1
+ Tab. 1).
Preparing mounting (Fig. 1, Fig. 2, Fig. 3):
1. Make bore (øD) with distance (L1) to the driving shaft
2
.
2. Pay attention to the diameter of the drive shaft
2
.
