DE04 DE04/1 DE10

Commissioning English

DE04 DE04/1 DE10 · Date 10.12.2012 · Art. No. 84260 · Mod. status 384/12

5.2 Zeroing/calibration (only key pad operation directly or

delayed)

The position value can be set to the programmed calibration value by

means of the reset key .

This function serves for adjusting the absolute position value to the

mechanical measurement.

The reset function can be delayed by 5s by means of parameters in order

to avoid accidental reset.

5.3 Incremental measurement (only key pad operation directly,

delayed or only incremental measurement key)

Upon activation or de-activation of the incremental measurement func-

tion the function key must be pressed only a short time. An activated

incremental measurement function will be indicated by the incremental

measurement function symbol in the display.

Incremental measurement enables relative as well as absolute measure-

ments to be displayed. With incremental measurement activated, the

absolute value is still recorded in the background.

By actuating the incremental measurement key , the user changes the

position indication from absolute indication to incremental measurement

indication. Active incremental measurement indication is signalled by the

incremental measurement symbol .

Upon activation of incremental measurement the display changes to "0".

Now, relative measurement can be set starting from this position.

As soon as the incremental measurement key is pressed anew, the

display will change to absolute measurement again. The incremental mea-

surement symbol will disappear.

5.4 Entry of calibration value (only key pad operation directly or

delayed)

The calibration value can be entered as follows.

After pressing the calibration value entry key for more than 5s, the

current calibration value as well as the calibration value entry symbol

will be displayed.

The calibration value can now be set to the desired value by pressing the

or key. If the two keys are pressed for more than 5s, the value

will ascend or descend independently.

NOTICE
