MA503/1-S
Documentation English
MA503/1-S · Date 05.09.2016 · Art. No. 80994 · Mod. status 151/16
12
1 Documentation
There are further relevant documents - see list in original installation
instruction.
These documents can also be downloaded at "http://www.siko-global.
com/en-de/service-downloads/download-products".
2 Safety information
Safety information of original installation instruction apply.
3 Key functions
Depending on the operating mode the keys may have additional func-
tions (see chapter 4 and 6). The keys are pressed singly or in pairs (two
together).
1
Programming key
2
Select 'value' key
3
Select 'digit' key
4
Store value key
5
ON / OFF
6
Display: incremental mea-
surement function / bat-
tery change / sign
Fig. 1: Key functions EG, TF
Fig. 2: Key functions ES
4 Programming mode
Ex works, the display is delivered with standard settings or customized.
Switch over to the programming mode if you want to change the settings
and reprogram the device. Normally, programming is only necessary at ini-
tial commissioning and set-up of the display or application, respectively.
