Siko MA503/1 Additional Manual

MA503/1-S
Application Examples English
MA503/1-S · Date 05.09.2016 · Art. No. 80994 · Mod. status 151/16
17
Message Description Action
is on /
MA503/1 cannot be
referenced
Display is still in
incremental measure-
ment function.
Quit incremental measurement function as
described in chapter 6.2 or proceed as fol-
lows:
1. Enter into programming mode.
2. Program parameter 'F_rEL' to "on".
3. Quit programming mode.
4. Quit incremental measurement function as
described in chapter 6.2.
5. Enter programming mode again.
6. Program parameter 'F_rEL' to "oFF".
7. Quit programming mode.
9 Application Examples
Length measurement
Required: Display accuracy 1/10mm. Display shall be zeroed via function
key.
Designation Display Progr. value
Resolution rES 0.1
Decimal point dP 0.0
Reference value rEF 00000.0
Oset oFS 00000.0
Counting direction dir uP
Switch-o method Auto oFF
Last value memory rSto oFF
Delayed switch-o 4_oFF oFF
Reset function enable F_Abs on
Increm. meas. function enable F_rEL oFF
Reference value change enable F_rEF oFF
Oset correction enable F_oFS oFF
Language LAn E
Angle measurement
Required: display range 0 ... 360°; display accuracy 1/10°. Display to be
zeroed via front key. Automated device switch-o after 0.5h.
Conditions: circular disk with ø300mm; resulting total circumference: U =
π x 300mm = 942.48mm
