MA503/1-S

Input mode English

MA503/1-S · Date 05.09.2016 · Art. No. 80994 · Mod. status 151/16

Display

"choice"

Designation / description

F_oFS Oset value enable: to enter / change the oset value.

"oFF" Oset value function o

"on" Oset value function on

LAn Language: to choose the language in which the menu items

are to be displayed.

"d" German

"E" English

6 Input mode

6.1 Reset function via keyboard

Precondition: The menu item 'Reset enable' (F_AbS) in programming

mode must be programmed to "on” and the display is not in programming

mode (see chapter 4 'To leave programming mode').

• Press key to reset the display to the reference value.

• If menu item 'delayed reset function' (4_Abs) is programmed to "on",

the display will be reset to the reference value after approx. 4s.

6.2 Incremental measurement

Precondition: Menu point 'Incremental measurement enable' (F_rEL) in

programming mode must be programmed to "on" and the display is not in

programming mode (see chapter 4 'To leave programming mode').

Press the two arrow keys + simultaneously to activate incremental

measurement function.

• The display is zeroed.

• The display shows the symbol .

• Deactivate incremental measurement function by another simultane-

ous pressing of the two arrow keys + . The absolute measuring

value is displayed again.

• While in the incremental measurement mode the display can also be

set to zero by pressing key . This does not change the absolute

measurement in the background.
