MA503/1-S
Parameter description English
MA503/1-S · Date 05.09.2016 · Art. No. 80994 · Mod. status 151/16
14
Display
"choice"
Designation / description
dP Decimal point (only possible if resolution = 'FrEE'): Deter-
mination of the decimal point according to the resolution.
rEF Reference value: Absolute reference point of the measuring
system. This value is set by referencing the system accord-
ing to chapter 6.
oFS Oset: Freely selectable value that influences the display.
Oset can be used as tool correction value for example.
dir Counting direction of the measuring system: depends on
the sensor's mounting position and can be changed subse-
quently.
"uP" Upward
"dn" Downward
Auto Switch-o type (sleep mode): Operating mode of auto-
mated switch-o.
"oFF" no switch-o
"on" With automated switch-o
PEriod Switch-o time: Period between the last measurement and
automated switch-o.
rSto Last value memory
"oFF" Last value memory o. When switched on, the display must
be calibrated (zeroed).
"on" Last value memory on. When switched on, the last mea-
sured value is displayed.
4_oFF Delayed switch-o: ON/OFF key must be pressed for approx.
4s to switch o the display.
4_Abs
Delayed reset function: Key must be pressed for approx.
4s to reset the display to reference value.
F_AbS Reset function enable: resetting to reference value via key
on front keyboard.
"oFF" Reset function o
"on" Reset function on
F_rEL Incremental measurement enable: to switch from absolute
dimension and zero-setting to subsequent relative dimen-
sion.
"oFF" Increm. meas. function o
"on" Increm. meas. function on
F_rEF Reference value enable: to enter / change the reference
value.
"oFF" Reference value function o
"on" Reference value function on
