SILENCE S01+ - Battery Specifications

MU_S01 MY22_EN - User Manual S01 MY22 (V006) Page 44 of 68 Copyright© SILENCE Urban Ecomobility
BATTERY SPECIFICATIONS
Nominal capacity
4.1 kWh
(S01 Basic)
5.6 kWh
(S01 Con. - Std - Plus)
Cell chemicals
Lithium-ion cells
Weight
36 kg
41 kg
Unfolded height
870 mm
Box height
270 mm
Wheel width
330 mm
Box depth
440 mm
Nominal voltage of the battery
51 VDC
Storage temperature (not charging)
-20 a 45 ºC (max.) / 0 a 25 ºC (recommended)
Operating temperature
0 a 50 ºC (charging) / -10 a 60 ºC (use, discharging)
Housing material
Aluminium and PC
Max. charging current
30 A
35 A
Max. discharge current
160 A
280 A
Type of charger
Onboard 90-240 VAC; 600 W
Max. internal charger current
10.2 A
Standard charge time
5-7 h
7-9 h
