Thank you for choosing this Silonn product! At Silonn we strive to
provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
Technical Support: 877-546-8603 Mon-Fri 8am - 8pm (CST)
Other Info: support@silonnus.com
Model: SLIM02
V1.0 (A)
Ice Maker Instruction Manual

Questions and Answers

  • A
    annettebradleyAug 7, 2025
    What to do if there is no water running down from the separator pipe in Silonn SLIM02?
    • S
      stephanielopezAug 7, 2025
      If water isn't running down from the separator pipe in your Silonn Ice Maker, it may be because the holes are blocked. Try using a slim wire to prick each hole until water can flow out easily. Alternatively, the water filter might be blocked, so try cleaning it.
  • K
    Kristin WilkersonAug 14, 2025
    How to fix ice cubes that are too thick in Silonn SLIM02 Ice Maker?
    • J
      John HillAug 15, 2025
      If the ice cubes from your Silonn Ice Maker are too thick to drop down, the ice-making cycle might be too long. Try pressing “-” to reduce the ice-making cycle time.
  • S
    shawna73Aug 22, 2025
    What to do if the indicator light is on for Silonn SLIM02?
    • S
      Sharon FreemanAug 22, 2025
      If the indicator light is on for the Silonn Ice Maker, it could be due to several reasons. First, check if there is a lack of water; if so, turn off the unit, add water to the level, and restart it. Another cause could be ice cubes overloading the basket, in which case you should remove some ice. It may also indicate a failure of the inlet solenoid valve or the ambient/water temperature sensor, for which you may need a technical service person or to change a new sensor.
  • S
    Sonya ThomasAug 30, 2025
    Why are the ice cubes too thin in my Silonn SLIM02 Ice Maker?
    • A
      Anna JacksonAug 30, 2025
      If the ice cubes produced by your Silonn Ice Maker are too thin, it could be due to several reasons. The ambient temperature or the water temperature might be too high. Try moving the unit to a cooler place and ensure the water temperature does not exceed 25°C (77°F). Also, the ice-making cycle might be too short; in this case, press “+” to increase the ice-making time. If the ambient temperature is high or the water temperature is high, move the unit to somewhere where the ambient temperature is lower than 30°C (86°F), and fill it with cool water. In rare cases, refrigerant system leakage could be the cause, which would require assistance from a technical service person.

Summary

Important Safety Instructions

Safety Information (Grounding)

Product Description

Cleaning and Maintaining Your Ice Maker

Before First Use

Instructions for cleaning the ice maker before its initial operation.

After Long-Term Use

Procedures for cleaning the ice maker after extended periods of non-use.

Storage

Guidelines for storing the ice maker when not in use for extended periods.

Operation Panel and Display Area

Control Buttons Overview

Details the functions of the TIMER/CLEAN, ON/OFF, and adjustment buttons.

LCD Display Window

Explains the various symbols, codes, and indicators on the ice maker's display.

Using Your Ice Maker

Preparing for Use

Steps for correctly positioning and preparing the ice maker before operation.

Ice Making Operation

Detailed instructions on how to fill water and start the ice making process.

Setting Ice Thickness

Instructions on adjusting the ice cube thickness.

Self-Cleaning Function

Guide on how to initiate and cancel the self-cleaning program.

Setting the Timer

Instructions for setting the automatic on/off timer for the ice maker.

Draining Water

Procedures for draining water from the ice maker's tank and reservoir.

Troubleshooting

Technical Parameters and Circuit Diagram

Silonn SLIM02 Specifications

General IconGeneral
ModelSLIM02
Weight17.6 lbs
Power Consumption120W
Voltage110-120V/60Hz
MaterialStainless Steel & ABS
Warranty1 year
Ice Production Capacity26 lbs per day
Ice ShapeBullet
Water Reservoir Capacity2.2 liters
Ice Making Capacity26 lbs per day
Water Tank Capacity2.2 liters
Noise Level≤45 dB
