Silva NX2 User Manual

5FAULTFINDNX2.doc Page 4 Latest update: 24 Feb -03
NMEA in No values Wrong NMEA sentences
transmitted
Check set-up in the transmitting unit
Position no values Incorrect selection of position
source
Correct selection of position source Config Nexus / NMEA
position in GPS Navigator
Position wrong values Incorrect setting of
minutes/seconds, C38
Correct setting of C38 C38
Push button No sound Wrong setting of C71=OFF Set to C71= ON C71/Set C71 = ON
Push button No sound If correct setting of C71
Fault in Instrument
Fault in Instrument
Replace
REM
Remote Control
Two Instruments
react on comands
Same ID-No on two
Instruments
Make a Re-Initialisation so that every
Instrument get its own ID-No.
Speed no speed [- - -] Wrong setting of SOG, set to
ON but no navigator
connected
Set SOG to OFF C95/ Set C95 = OFF
(SOG)
Speed Speed value is
0.00
Impeller is not rotating? take up the transducer and turn the
impeller. Log diode should blink and
speed value on instrument.
Blinking diod indicate OK
Log transducer.
Speed no speed [0.00] Impeller is not rotating Clean the impeller
Speed no speed [0.00] Impeller is not rotating, due to
remaining antifouling inside
the through hull fitting
Clean the through-hull fitting
Speed wrong values Wrong units Correct setting of units C11
Speed wrong values Incorrect calibration value Correct calibration C12
Speed wrong values Incorrect setting of damping Correct setting of damping C13
Speed wrong SOG-
values
Incorrect setting of damping Correct setting of damping C72
Temperature No Temp. (- - -) Connections, wires, lose end Correct connect. Check. White to ground ~1,8 V White to ground
Temperature Wrong Temp.
value
Incorrect calibration value Correct calibration C23, C24
Wind no values [- - -] Nexus wind transducer but
C76 set to ON
Set C76 to OFF C76
Wind no values [- - -] NMEA wind transducer and
C76 set to OFF
Set C76 to ON C76
Wind wrong speed
values
Wrong units Correct setting of units C53
Wind wrong wind
angle
Wrong selection of wind angle Correct selection of wind angle C52
Wind wrong wind
angle
Incorrect setting of mast top
unit misalignment
Correct setting of mast top unit
misalignment
C55
Wind wrong wind
angle
Incorrect setting of wind
calibration values
Correct setting of wind calibration values C56 to C63
Wind wrong values Poor cable connection Check connections wind transducer /
cable through deck connectors
Wind wrong values Incorrect setting of damping Correct setting of damping C65
Wind no values [- - -]
Wind Data
C71 incorrect set to [ON]
(Wind Data)
Correct setting to [OFF] C71 Wind Data
Wind Wind function
not available in
Multi Control
Incorrect setting of Page Auto
C51
Set C51 to PAGE ATO or PAGE ON C51
